Ürün Bilgisi
Açıklama
| DONANIM ÖZELLİKLERİ | |
|---|---|
| Arabirim | • 9× 10/100/1000 Mbps RJ45 Ports (Ports 1–8 supports PoE+ output) • 1× Gigabit SFP Port |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Sayısı | Fanless |
| Kurulum | • Desktop • Wall Mounting |
| Fiziksel Güvenlik Kilidi | Yes |
| Güç Kaynağı | External Power Adapter(Output: 53.5VDC / 1.31A) |
| PoE+ Portları (RJ45) | • Standard: 802.3at/802.3af compliant • PoE Ports: Ports 1–8, up to 30 W PoE output per port • PoE Power Budget: 61W |
| Boyutlar ( W X D X H ) | 8.2×4.9×1.0 in (209×126×26 mm) |
| Maks. Güç Tüketimi | • 7.3 W (220/50Hz. no PD connected) • 76.96 W (220/50Hz. with 61 W PD connected) |
| Max Heat Dissipation | • 24.82 BTU/h (no PD connected) • 261.66 BTU/h (with 61 W PD connected) |
| PERFORMANS | |
|---|---|
| Anahtarlama Kapasitesi | 20 Gbps |
| Paket Yönlendirme Hızı | 14.88 Mpps |
| MAC Adres Tablosu | 4K |
| Jumbo Frame | 16 KB |
| YAZILIM ÖZELLİKLERİ | |
|---|---|
| Gelişmiş Özellikler | • Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission) • Isolation Mode Button (Ports 1–8) • PoE Auto Recovery Button (Ports 1–8) • Compatible With IEEE 802.3af/at Compliant PDs • IEEE802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping • Green Technology |
| İletim Metodu | Store-And-Forward |
| DİĞERLERİ | |
|---|---|
| Sertifika | CE, FCC, RoHS |
| Paket İçeriği | • LS1210GP • Power Adapter • Installation Guide |
| Ortam | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing |
