Ürün Bilgisi
Açıklama
- General
- ShellMetal material
- Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Power Supply100 to 240 VAC, 50/60 Hz, Max. 2.5 A
- Storage Humidity5% to 95% (no condensation)
- Net Weight1.8 kg (4.0 lb)
- Gross Weight2.58 kg (5.69 lb)
- Dimension (L × H × D)266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)
- Operating Humidity5% to 95% (no condensation)
- Power Consumption In Idle20 W
- Network Parameters
- Port Number16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical port
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- Working ModeStandard mode (default); Extend mode
- MAC Address Table4 K
- Switching Capacity7.2 Gbps
- Packet Forwarding Rate5.356 Mpps
- Internal Cache2.75 Mbits
- High Priority PortsPorts 1 to 8
- Ports For Long-Distance TransmissionPorts 9 to 16
- PoE Power Supply
- PoE StandardIEEE 802.3af, IEEE 802.3at
- PoE Power Pin
Ports for long-distance transmission (9-16) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.
Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.
- PoE PortPorts 1 to 16
- Max. Port Power30 W
- PoE Power Budget130 W
- Max. Power Consumption150 W
